kwikset smartcode 917 user manual

2.1 Latch and Exterior Assembly

The latch and exterior assembly of the Kwikset SmartCode 917 are pre-assembled for ease of installation. The latch ensures smooth door operation‚ while the exterior assembly includes the keyless entry keypad and lock cylinder. These components are designed to withstand various weather conditions and provide a durable‚ secure locking mechanism for your door.

2.2 Interior Assembly and 9V Battery

The interior assembly of the Kwikset SmartCode 917 includes the control board‚ battery compartment‚ and mounting hardware. It is powered by a single 9V battery‚ which provides energy for all electronic features. The battery is located in the interior assembly and is essential for operating the lock’s keyless entry‚ programming‚ and security functions. Regular battery checks are recommended to ensure uninterrupted performance.

Installation Process

Installing the Kwikset SmartCode 917 involves removing the old lock‚ preparing the door‚ and mounting the new latch and exterior and interior assemblies. Required tools include a screwdriver and Allen wrench for secure installation‚ ensuring proper alignment and functionality.

3.1 Preparing the Door and Checking Dimensions

Before installation‚ ensure the door is properly prepared. Measure the door thickness (typically 1.75 inches) and backset (2.75 inches or 2.375 inches). Verify the hole alignment for the latch and handle. Clean the area around the lock opening to ensure proper fitment. Check that all existing holes match the lock’s specifications to avoid installation issues.

3.2 Step-by-Step Installation Instructions

Begin by removing the old lock and hardware. Attach the new latch to the door‚ ensuring proper alignment. Install the exterior assembly‚ then connect the wires to the interior side. Secure the interior assembly and tighten all screws. Insert the 9V battery and test the lock’s functionality. Follow the manual for precise alignment and tightening to ensure smooth operation.

Programming the SmartCode 917

Program user codes and master codes by following the manual’s instructions. Remove the battery cover‚ press the program button‚ enter codes‚ and confirm with the lock button.

• Open the door and remove the battery cover to access the program button.
• Press the program button once to enter programming mode.
• Enter your desired 4-8 digit user code using the keypad.
• Press the lock button to confirm the code.
• If successful‚ the lock will confirm with a green light or sound.
• Repeat for additional codes or press the program button to exit.

4.2 Programming the Master Code

4.1 Setting Up User Codes

• Open the door and remove the battery cover to access the program button.
• Press the program button once to enter programming mode.
• Enter your desired 4-8 digit user code using the keypad.
• Press the lock button to confirm the code.
• If successful‚ the lock will confirm with a green light or sound.
• Repeat for additional codes or press the program button to exit.

Key Features and Functions

• Keyless entry with customizable user codes for enhanced convenience.
• SmartKey Security for advanced protection against break-ins.
• Auto-lock feature for hands-free secure locking.
• Long-lasting 9V battery life with low-battery alerts.
• Backlit keypad for easy access in low-light conditions.

5.1 Auto Lock Feature and Its Activation

The Kwikset SmartCode 917 features an auto-lock function that automatically secures the door after a set period. To activate‚ open the interior battery cover‚ locate the auto-lock switch‚ and move it to the “on” position. This hands-free feature enhances security and convenience‚ ensuring your door is always locked without manual intervention. Follow the user manual for precise activation steps to tailor the timing to your preference.

5.2 SmartKey Security for Enhanced Protection

The Kwikset SmartCode 917 features SmartKey Security‚ offering superior protection against break-ins and unauthorized access. This advanced technology allows homeowners to re-key the lock themselves in seconds‚ eliminating the need for professional assistance. SmartKey Security enhances the lock’s resistance to forced entry‚ providing peace of mind and added convenience for home security management. It seamlessly integrates with the lock’s other advanced features.



Troubleshooting Common Issues

Troubleshooting the Kwikset SmartCode 917 involves addressing keypad responsiveness‚ battery life‚ and connectivity problems. Regularly check the keypad for dirt and ensure batteries are fresh for optimal performance.

6.1 Keypad Not Responding or Malfunctioning

If the keypad stops responding‚ ensure it is clean and free of debris. Replace the 9V battery if power is low. Check for loose connections or damage. Reset the lock by removing the battery and pressing the program button for 10 seconds before reconnecting. If issues persist‚ contact Kwikset customer support for further assistance or potential replacement.

6.2 Battery Life and Power Issues

The Kwikset SmartCode 917 typically operates for 12-18 months on a 9V battery. Low battery warnings include slow keypad responses or dim LED lights. Replace the battery promptly to avoid lockout. Clean battery terminals and ensure proper installation. If issues persist‚ reset the lock by removing the battery and pressing the program button for 10 seconds. Contact support if power problems continue.



Maintenance and Care Tips

Regularly clean the keypad with a soft cloth and mild detergent. Lubricate moving parts annually. Avoid harsh chemicals. Ensure the exterior finish is wiped clean periodically.

7.1 Cleaning the Keypad and Exterior

Use a soft‚ dry cloth to wipe the keypad and exterior. For tougher dirt‚ dampen the cloth with mild detergent‚ but avoid harsh chemicals or abrasive materials. Regular cleaning prevents dust buildup and maintains functionality. Gently remove fingerprints and smudges to ensure optimal performance and longevity of the lock’s finish and electronic components.

7.2 Replacing the Battery

Replace the 9V battery when the low-battery indicator flashes. Open the interior cover by removing the screws. Carefully lift the battery compartment‚ ensuring correct orientation of the new battery. Avoid touching internal components to prevent static damage. After installation‚ test the lock’s functionality by entering a user code or using the key. Dispose of the old battery responsibly and consider keeping a spare for future use.

Accessing the User Manual and Additional Resources

Download the Kwikset SmartCode 917 user manual as a PDF from the official Kwikset website or through their support section. Additional resources‚ including installation guides‚ are available online.

8.1 Downloading the PDF Manual

To download the Kwikset SmartCode 917 user manual‚ visit the official Kwikset website. Navigate to the support section‚ select your product‚ and click on ” Manuals & Guides.” The PDF manual is available for free download‚ providing detailed installation‚ programming‚ and troubleshooting instructions. Ensure to download the correct version for your specific SmartCode 917 model.

8.2 Online Support and FAQ Sections

Kwikset offers comprehensive online support for the SmartCode 917‚ including a dedicated FAQ section. Visit their website to find answers to common questions‚ troubleshooting tips‚ and programming guides. The support page also provides access to installation videos‚ user manuals‚ and contact information for customer service‚ ensuring all your queries are addressed efficiently.



Multimedia and Video Guides

Kwikset provides video guides for the SmartCode 917‚ including installation tutorials and programming demonstrations. These resources are available on their official website‚ offering visual step-by-step instructions to help users understand and utilize the lock’s features effectively.

9.1 Installation Videos

Kwikset offers installation videos for the SmartCode 917‚ providing step-by-step guidance for a smooth setup. Available on their official website‚ these videos cover preparing the door‚ assembling components‚ and securing the lock. They also include troubleshooting tips and visual demonstrations to ensure proper installation‚ making the process easier for DIY enthusiasts and professionals alike.

9.2 Programming Tutorials and Demos

Kwikset provides programming tutorials and demos for the SmartCode 917‚ available on their website and YouTube. These guides explain how to set up user codes‚ program the master code‚ and utilize the SmartKey feature. Step-by-step instructions and visual demonstrations ensure users can easily master the programming process‚ making it accessible for both new and experienced users to customize their lock settings efficiently.

Customer Support and Warranty Information

Kwikset offers customer support at 1-800-327-5625 and provides a 1-year electronic warranty for the SmartCode 917‚ ensuring assistance and protection for users.

10.1 Contacting Kwikset Customer Service

Kwikset customer service is available at 1-800-327-5625 for assistance with the SmartCode 917. Additionally‚ users can visit www.kwikset.com for support resources or email ConsumerService@kwikset.com. Representatives are available Monday through Friday‚ 7 AM to 7 PM Central Time‚ to address inquiries and provide solutions for any issues related to the product.

10.2 Warranty Details and Claims Process

Kwikset offers a one-year electronic warranty for the SmartCode 917‚ covering defects in materials and workmanship. For mechanical components‚ a lifetime limited warranty applies. To file a claim‚ contact customer service at 1-800-327-5625 or via email. Proof of purchase and product details may be required. Visit www.kwikset.com for full warranty terms and conditions.
